Kirisun DP770 User Manual

DP770 Digital Portable Radio Instruction Manual
5
Rotate the knob to adjust the volume.
Short press the key, the function of the knob switches from adjusting the volume to changing the
channel.
C. LCD Display
160*128, 65K colors, 1.8 TFT LCD.
D. Universal Connector for accessories
Connect USB programming cable, earphone or some other accessories.
E. Top Key (TK)
Programmable, default: short press to enable emergency alarm, long press to exit emergency
alarm.
F. LED Indicator
G. Side Key 1 (SK1)
Programmable, default: none.
H. PTT Key
I. Side Key 2 (SK2)
Programmable, default: none.
J. Left Key
Press the key to select the items shown at the bottom left of the screen.
K. Dial Key
Press the key to send the data or text messages.

Kirisun DP770 Specifications

General

Brand	Kirisun
Model	DP770
Category	Radio
Language	English
