2-5
INSTALLING THE ANTI-TIP BRACKET
PARTS SUPPLIED
Plastic Anchors Screws
Anti-Tip Bracket
NOTE: The anti-tip bracket can be installed to
hold either the right or left rear leg of the range.
1. Determine which leg you wish to anchor to
the floor.
2. Place the anti-tip bracket template on the
floor in the range opening so that the top
edge is against the wall, molding, or cabi-
net, and the bracket template is in the
location where the anti-tip bracket will be
installed.
3. Tape the template to the floor.
Template
NOTE: For mounting to a wood floor, proceed
to step 4. For concrete or ceramic floors, pro-
ceed to step 5.
Template
Tip-Over Hazard
A child or adult can tip the range and
be killed.
Connect anti-tip bracket to rear range
foot.
Reconnect the anti-tip bracket, if the
range is moved.
Failure to follow these instructions can
result in death or serious burns to
children and adults.
WARNING
To Next Page
