KitchenAid KDRP487MSS - Removing the Oven Door Gasket

4-29
REMOVING THE OVEN DOOR GASKET
1. Open the oven door to its fully open posi-
tion.
2. Remove the screw from the door gasket
bracket and remove the bracket from the
range.
REASSEMBLY NOTE: When you install the
new gasket, make sure that all of the clips are
seated in their liner holes, and that the ends of
the gasket are pushed fully into their holes. Use
the pointed end of a pencil to push the gasket
ends into the holes.
Gasket BracketScrew
3. Pull the ends of the gasket out of the liner
holes.
Door Gasket
Gasket Clip
