LOCATION REQUIREMENTS
IMPORTANT: Observe all governing codes and
ordinances. Failure to meet codes and ordi-
nancescouldleadtoreorelectricalshock.
Proper installation is your responsibility.
Contactaqualiedinstallertoensurethatthe•
dishwasher is installed to meet all electrical
and plumbing national and local codes and
ordinances.
Installthedishwasherasspeciedinthese•
instructions.
Have everything you need to properly install •
dishwasher.
Protect dishwasher and water lines leading to •
dishwasher against freezing. Damage from
freezing is not covered by the warranty.
This dishwasher is manufactured for indoor •
use only.
Installandleveldishwasheronaoorthat•
will hold the weight, and in an area suitable
PRODUCT DIMENSIONS
23"
(59.5 cm)
33
"
85.8 cm)
19
"
(48.9 cm)
1
"
(3.75 cm)
24"
(61 cm)
34"
(86.4 cm
INSTALLATION CLEARANCES
Cutout dimensions
23 "
24"
(61 cm)
33"
(85.7 cm)
(59.7 cm)
Preferred utililty area
A. Choose left-hand or right-hand drain and water connection route.
B. Choose left-hand or right-hand electric connection route.
A
B
25"
(63.5 cm)
1/2"
(1.3 cm)
8"
(20.3 cm)
NOTE: All holes should be drilled at 1/2"
(3.8 cm) diameter.
WATER SUPPLY REQUIREMENTS
A hot water line with 20-120 psi (138-862 •
kPa) water pressure.
120°F (49°C) water temperature at dish-•
washer.
F l e x i b l e s t a i n l e s s s t e e l b r a i d e d l l l i n e ( ½" m i n -•
imum plastic tubing is not recommended).
