4-7
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or electrical shock.
REMOVING A PUMP
1. Unplug dishwasher or disconnect power.
2. Turn off the water supply to the dishwasher.
3. Remove the tub (see “Removing The
Tub,” page 4-6).
4. Remove the four bottom cover screws and
remove the cover.
5. Remove the two screws holding the pump
to the tub (see the top right photo).
6. Loosen the two hose clamp screws, pull
the hoses off, and remove the pump.
7. Remove the wiring connector from the
pump.
Bottom Cover Screws
Pump Screws
Clamp Screws
Wiring Connector
To Next Page
