4-11
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or electrical shock.
REMOVING THE FRONT PANEL, INTERMEDIATE PANEL,
AND THE CONTROL HOUSING
1. Unplug dishwasher or disconnect power.
2. Turn off the water supply to the dish-
washer.
3. Remove the tub and bottom cover (see
pages 4-6 & 4-7).
4. To remove the front panel on classic
model:
a) Remove the two screws from the un-
derside of the front panel.
b) Slide the front panel down and off of
the front of the tub.
5 To remove the front panel on premium
model:
a) Remove the six screws from the back
sides of the front panel.
b) Slide the front panel up and off of the
front of the tub.
Continued on the next page.
