KitchenAid KUDD03DT Series User Manual

4-18
7. Squeeze and remove the tube from the
valve body. NOTE: There is an O-ring and
duck bill at the end of the tubes.
NOTE: When reassembling, insert the
duck bill into the valve body before in-
stalling the tubing.
Remove Tube
Tube O-Ring
Flow Meter
Connector
