KitchenAid Pro Line KHEV01RSS - Diagnostics & Troubleshooting; Electric Dryers; Display Fault;Error Codes

6-1
ELECTRIC DRYERS
DIAGNOSTICS & TROUBLESHOOTING
DISPLAY FAULT/ERROR CODES
The error codes below would be indicated when
attempting to start a drying cycle, or after acti-
v
ating the Diagnostic Test mode.
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or electrical shock.
WARNING
DISPLAY DESCRIPTION EXPLANATION AND RECOMMENDED PROCEDURE
PF
POWER
FAILURE
PF flashes to indicate that a power failure occurred
while the dryer was running. Press Start to continue
the cycle, or press Pause/Cancel to clear the display.
Refer to TEST #1.
E1
TEMPERATURE
SENSOR OPEN
E1 flashes in the numeric display when the
temperature sensing circuit is open.
Refer to TEST #3a.
E2
TEMPERATURE
SENSOR
SHORTED
E2 flashes in the numeric display when the
temperature sensing circuit is shorted.
Refer to TEST #3a.
E3
BLOWER
ROTATION
FAILURE
If during a cycle the blower rotational speed drops
below 500 rpms, all outputs will be turned off and
error code E3 will be displayed.
Refer to Diagnostics Tests, Diag Test #2.
E4
TUMBLER
ROTATION
FAILURE
If during a cycle the tumbler rotational speed drops to
0, all outputs will be turned off and error code E4 will
be displayed.
Refer to Diagnostics Tests, Diag Test #2.
E5
DRY RACK
SENSOR
If during a Dry Rack cycle the signal is lost, all outputs
are turned off and E5 is displayed.
Refer to TEST #8.
E6
EXHAUST
HIGH LIMIT
FAULT
If the exhaust temperature goes above 190°F (87.7°C)
all outputs will turn off and E6 will be displayed.
Refer to TEST #3b.
