SPECIFICATIONS
MODEL NUMBER KHEV01RSS KHGV01RSS
CAPACITY (cu ft) 6.7 cu ft
WRINKLE PROTECTION (Extra Care)
Extended INTERMITTENT 150 MIN. On/Off Option Yes - Default on in Norm / Casual mode only
TEMPERATURE SETTINGS
EXTRA HIGH (°F) - HEAVY DUTY Yes - (165°F)
HIGH (°F) - WHITE / COTTON Yes - (160°F)
MEDIUM (°F) - NORMAL / CASUAL (Default Cycle) Yes - (150°F)
LOW (°F) - DELICATE Yes - (135°F)
EXTRA LOW (°F) - SUPER DELICATE Yes - (120°F)
AIR DRY Yes
UTILITIES
BELT 6 Groove, poly V
FREQUENCY 60 Hz
MOTOR RATING- DRUM 1/4hp 115/240 volt
MOTOR RATING - Blower / Fan 1/8hp 115/240 volt
HEATER ELEMENT Single 5.4kw
GAS BTU 20,000 BTU
DIMENSIONS (UNCRATED)
HEIGHT (w/legs full up) 41.5˝
HEIGHT (w/feet extended 1˝) 42.5˝
WIDTH 27˝
DEPTH (with Handle) 33.5˝
PRODUCT WEIGHT Gas 264 lbs. / Electric 262 lbs.
