6-19
Diagnostic: Console switches and indicators
Pressing each button or turning the cycle se-
lector to each cycle should cause a beep tone
and control one or more LEDs as shown in Fig-
u
re 1. The Estimated Time Remaining display
will indicate a software project i.d. number.
Diagnostic: Moisture Sensor
Locate
two metal strips on the inside right wall
or the door well. Bridge these strips with a wet
cloth or a finger. If a continual beep is heard,
the sensor is OK. If not, or if a beep tone is
heard before bridging the moisture strips, go
to TEST #4, step 2.
Diagnostic: Door Switch
Opening
the door should cause GAS to be
displayed. Closing the door firmly should cause
the display to indicate the software revision.
Deactivating The Diagnostic Test #1 Mode
Press Pause/Cancel to exit Diagnostic Test
#1 mode.
DIAGNOSTIC TEST #2 –
MACHINE OPERA
TION
Activating The Diagnostic Test #2 Mode
1. Be sure the dryer is in Standby Mode
(plugged in and all indicators off).
2. Press the following button sequence, all
within 3 seconds:
Dryness
Level
Manual Dry
Time (–)
Dryness
Level
Manual Dry
Time (–)
g g g
3. After a 2 second pause, Diag will be dis-
played in the Estimated Time Remaining
display for 1 second, if this test mode has
been entered successfully.
4. Select any cycle and press Start to run
the dryer.
5. The table shows diagnostic information
that can be obtained while the dryer is
operating and by pressing and holding
the buttons shown in the next column:
Press button:
Results shown in Estimated
Time Remaining display:
Extra Delicate Exhaust temperature
Casual Tumbler rotation speed
Delicate Blower rotation speed
Heavy Duty Number of wet hits
Timed Dry
Number of running hours
Rapid Dry Software revision
g
g
g
g
g
g
Deactivating The Diagnostic Test #2 Mode
Press Pause/Cancel at any time to exit Diag-
nostic Test #2 mode.
NOTE: Diagnostic mode will automatically
exit
after 5 minutes of inactivity since the last
input from the user.
PROGRAMMING THE CONTROLS
If a new control board has been installed, fol-
low the steps below to select the appropriate
fuel (gas or electric).
Menu Mode
This
is an operation that is performed at the
factory to calibrate the temperature regulating
sensor/circuit and toggles between a gas and
electric machine (different routines for auto
cycle).
ACTIV
ATING THE MENU MODE
1. Be sure the dryer is in Standby mode
(plugged in and all indicators off).
2. Press the following button sequence, all
within 3 seconds:
3.
The Menu mode is active until Pause/
Cancel is pressed. After Pause/Cancel
is pressed, the unit will go into Standby
mode.
Pressing
Extra Delicate will set to a
gas model.
Pressing
Delicate will set to an electric
model.
4. Press Start to store setting changes.
DEACTIVATING THE MENU MODE
Pressing Pause/Cancel will exit the Menu mode
and enter the Standby mode.
•
•
Extra Care Extra Care Dryness Level Pause/Cancel
g g g
