Table 2-3 TCR with Pendant Control Dimensions
Cap.
(Tons)
Product
Code
Headroom
C
(in)
a
(in)
b
(in)
d
(in)
e
(in)
g
(in)
h
(in)
i
(in)
j
(in)
1/4
TCR250P
12
11.3
4
4.4
6.9
0.9
2.8
1.3
0.7
1/2
TCR500P
18.2
13.4
6.9
6.1
6.6
1.1
4.9
2.0
1.3
1
TCR1000P2
20.4
13.4
7.3
6.1
6.6
1.1
5.9
1.5
2.2
1
TCR1000P
18.3
13.4
6.9
6.1
6.6
1.1
4.9
2.0
1.3
2
TCR2000P2
21.8
13.4
7.6
6.1
6.6
1.1
6.0
1.6
2.3
3
TCR3000P
22.2
17.7
8.9
8.0
9.0
1.3
1.9
6.9
1.7
6
TCR6000P2
26.5
17.7
11.1
8.0
9.0
1.7
2.5
2.5
3.4
Single Fall Hoist Double Fall Hoist
Figure 2-1 Pendant Model TCR (See Table 2-3)
