9
Table 2-1 Hoist Specifications
Cap.
(tonne)
Product
Code
Standard
Lift
(ft)
Push
Button
Hose
L
(ft)
Up/Down Speeds
(ft/min @ 90 psi)
Up/Down
Air Consumption Rates
(cubic ft/min @ 90 psi)
Load Chain
Diameter
(mm)
x
Chain Fall
Lines
Net
Weight
(lbs)
Weight for
Additional
5 ft of Lift
(lbs)
No Load
w/Full Load
No Load
w/Full Load
Pendant Model
¼
TCR250M
6
6
55 / 41
26 / 54
32 / 25
28 / 28
4 x 1
24
---
¼
TCR250P
10
6
55 / 41
27 / 54
32 / 25
25 / 28
4 x 1
19
4
½
TCR500P
6
62 / 43
33 / 53
60 / 49
49 / 57
6.3 x 1
68
4
1
TCR1000P2
6
31 / 21
16/ 26
60 / 49
49 / 57
6.3 x 2
78
8
1
TCR1000P
6
34 / 21
19 / 30
60 / 53
49 / 60
7.1 x 1
75
5
2
TCR2000P2
6
17 / 10
10 / 15
60 / 53
49 / 60
7.1 x 2
88
10
3
TCR3000P
6
17 / 10
9 / 13
88 / 64
67 / 71
11.2 x 1
152
11
6
TCR6000P2
6
8 / 5
5 / 7
88 / 64
67 / 71
11.2 x 2
198
22
Cord Model
¼
TCR250C
10
6
61 / 45
29 / 57
35 / 28
28 / 32
4 x 1
15
4
½
TCR500C
6
62 / 43
33 / 53
63 / 49
49 / 57
6.3 x 1
66
4
1
TCR1000C2
6
31 / 21
16 / 26
63 / 49
49 / 57
6.3 x 2
76
8
1
TCR1000C
6
34 / 21
19 / 30
62 / 53
49 / 60
7.1 x 1
73
5
2
TCR2000C2
6
17 / 10
10 / 15
62 / 53
49 / 60
7.1 x 2
86
10
3
TCR3000C
6
17 / 10
9 / 13
90 / 64
67 / 71
11.2 x 1
150
11
6
TCR6000C2
6
8 / 5
5 / 7
90 / 64
67 / 71
11.2 x 2
196
22
2.2 Dimensions
Table 2-2 Top and Bottom Hook Dimension*
Units = inch
Product Code
a
b
c
d
e
f
g
h
TCR250C/P/M
0.8
0.8
0.6
0.8
1.4
1.7
0.9
2.9
TCR500C/P
1.4
0.9
1.1
0.9
1.6
1.6
1.1
4.2
TCR1000C/P2
1.4
0.9
1.1
0.9
1.6
1.6
1.1
4.2
TCR1000C/P
1.4
0.9
1.1
0.9
1.6
1.6
1.1
4.2
TCR2000C/P2
1.8
1.2
1.5
1.2
1.8
2.0
1.1
4.9
TCR3000C/P
2.0
1.5
1.7
1.3
2.0
2.4
1.3
5.9
TCR6000C/P2
2.3
1.6
1.9
1.6
2.6
2.8
1.7
6.8
*Refer to Section 5.7 for inspection dimensions and limits.
