Klemsan Meastro-R - SECTION 2 CONTROL; Manual Test Mode

56
Digital Astronomic Timer
Wthout logn, programs and settngs menus are not avalable for access
manually! Default password s 0001.
2.1 Manual Test Mode
Manual test mode usng for relay testng. When you press the button for 4 seconds, ashng
symbol becomes permanent lght and,
1
,
2
cons wll appear on the screen.That means C1
and C2 relays are passve condton and drectonal keys, respectvely, C1 and C2 relays can
be actvated. Pressng the same button agan, the relay that you want, became nactve. The actve
relays are ndcated by symbols on the screen
1
and
2
To ext manual mode, press the.
button for 4 seconds agan.
