AIR CONNECTION
Connect air line to connector at rear of machine as shown:
Note: Shop air should be between 80-110 PSI. Air volume
required, approx. 2-3 cfm.
FURTHER SUGGESTIONS:
Your air supply will certainly contain some moisture which is unavoidable in any plant air supply. The volume of
water vapor may amount to 5-6 gallons per day in the worst conditions. This water can rust the internal parts of
air tools, controls, and cylinders. It is for this reason that we suggest the installation of an air dryer in the line
(connection line 6), which will provide DRY AIR to your machine, eliminating unnecessary downtime due to
breakdowns, maintenance, and cleaning of rust, scale, and moisture.
Water in your machines operating system or cylinders is not covered under
warranty!
