INSTALLATION
We recommend that you follow these instructions closely
and report any problems to your distributor
Select an installation site that is clear of traffic and obstructions, suitable for proper machine operation and
maintenance, including adequate light and clearance. Machine may be transported via sling from ‘’eye” bracked
as illustrated.
The first step after uncrating your machine is to see that all items are present and that there is no apparent
damage to any part of the machine.
Checklist of items
C 370 SA-V Machine Operators manual
Wrenches One HSS Sawblade
Swiveling Handle
Note: Most of above items located in machine base. Open access
door by
unlatching latch in lower LH corner of door.
Your machine has been carefully packed and has preservative applied to
all metal surfaces to protect it during transit and storage. It is recommended that all of these surfaces be cleaned
at this time.
Check to insure that the gear reduction head contains the proper amount of oil. See section on Maintenance
(Gearbox), for proper oil level.
Mix coolant to approximately 10:1 with water for most sawing applications. . For Stainless Steal use a 5:1
mixture. For unusual materials, consult the manufacturer for additional coolant recommendations. Pour coolant
into the water in order to mix properly, then pour coolant into the coolant tank in the base of the machine.
Never use straight cutting oil!
Caution:
Ensure the removable chip tray is in the proper position
before you operate machine or pour in the coolant. The
removable chip tray slides easily into place and will drop into
place when in correct position.
Failure to observe this will allow coolant to flow into base
instead of into the reservoir.
Also note that a full chip tray is heavy. You must be prudent
to dispose of chips before the chip ban becomes too heavy.
View of chip tray and coolant reservoir.
Exact details may vary from various models.
