Kodak 2200 - Table 1: Type of Scissors Arms; Figure 2: Side View of KODAK 2200 Intraoral X-Ray System

SM731_K2200_01_en 06/2009
2-2
4. Scissor arm
• Wall-mounted with a choice of extensions
Figure 2: Side view of KODAK 2200 Intraoral X-ray System
Extension R Span A
CG 645 47,0 cm
(18.5 in.)
170.0 cm
(66 15/16 in.)
CG 646 64.8 cm
(25.5 in.)
188.0 cm
(74 in.)
CG 648 82.5 cm
(32.5 in.)
205.0 cm
(80 11/16 in.)
Table 1: Type of Scissors Arms
5. On/off switch
• Contains built-in light
6. Rectangular collimator (optional)
• Different sizes adapted to films and RVG sensors
Additional options
• Separate control timer
• Separate exposure switch (if the control panel is attached to the wall
framework)
• Wall-mounted unit for Irix replacement
• Ceiling-mounted unit
• Floor-mounted unit
• Unit mounted on mobile stand
