Kodak 2200 - Figure 3: KODAK 2200 Intraoral X-Ray System; Wall-Mounted Unit for Irix Replacement

06/2009 SM731_K2200_01_en
2-3
Wall-Mounted Unit for Irix Replacement
Figure 3: KODAK 2200 Intraoral X-ray System:
Replacement of Irix System
1. High-frequency x-ray generator
2. Wall framework
3. Control timer unit
4. Separate exposure switch
5. Scissor arm
6. Rectangular collimator
7. On/off switch with built-in light
