SM731_K2200_01_en 06/2009
6-4
X-ray Generator
TROPHY type TRX 708 CEI type OCX/65-G
Rated high voltage 70 kV 70 kV
Rated anodic power 490 W 490 W
Maximum heat
accumulated in the anode
8,700 J 10.000 J
Rated value of focal spot
(IEC 60336/1993)
0,7 mm (0.027 in.) 0.7 mm (0.027 in.)
Target materials Tungsten Tungsten
Target slope 19° 19°
Filtration due to fixed
materials
0,6 mm (0.023 in.) eq. Al 0,6 mm (0.023 in.) eq. Al
Table 5: Main characteristics of the x-ray generator
Figure 12: Heating and cooling curves for TROPHY TRX 708 tube
Figure 13: Heating and cooling curves for CEI OCX/65-G tube
