THEORY GUIDE Cassette Handling
10DEC05
TG4825-1
Page
45 of 120
CAM SENSORS:
• INNER CAM
SENSOR S10
• OUTER CAM
SENSOR S11
When the DUPLEX CAM moves to each of 4 positions, the RING
FLAGS block or unblock the path of the beam of the INNER and
OUTER CAM SENSORS. The status of the SENSORS is sent to the
MSC BOARD A1, which starts the motion of the DUPLEX CAM to the
next position.
RING FLAGS:
• HOME FLAG
• POSITION
FLAG
Block and unblock the path to the INNER CAM SENSOR S10 and
OUTER CAM SENSOR S11 when the DUPLEX CAM rotates.
Component Description
