PREVENTIVE MAINTENANCE
10DEC05
PM4825-1
Pag
e
23 of 30
Installing the New LEAF SPRINGS
1
Remo
v
e:
•
3 SCREWS
•
3 LEAF SPRINGS - discard
2
Install:
•
3 new LEAF SPRINGS
•
3 SCREWS
3
Continue with
Installing the New
FIXED LIGHT SEAL P
ADDLE
.
H194_1090GC
SPRINGS
3 LEAF
3 SCREWS
H194_1090GCA
22
24
