2-4 A-61560 January 2010
Attaching the optional
output tray kit
The Kodak i1200/i1300 Plus Series Scanners are shipped with an
output tray kit, which includes: an output tray extension, dangler and
clip. This output tray is optional but is recommended when scanning
large stacks of documents.
To install the output tray kit:
1. Remove the standard output tray from underneath the scanner by
pressing down on the two tabs and pulling the output tray out of
position.
2. Press and hold the tilt button and rotate the scanner body to the
downward position.
NOTE: The scanner must be in the downward position when using
this output tray.
clip
dangler
output tray extension
