A-61560 January 2010 1-5
Back view
Power switch — turns the scanner on and off.
Power port — connects the power cord to the scanner.
USB port — connects the scanner to the PC.
Flatbed port — connects the optional flatbed accessory to the scanner.
Security lock port — connects a security lock to the scanner. You can
purchase a standard security lock at an office supply store. Refer to the
instructions provided with the security lock for installation procedures.
Power switch
Power port USB port
Flatbed port
Security
lock port
