Kodak PIXPRO WPZ2 User Manual

1
Declaration of Conformity
Responsible Party: JK Imaging Ltd.
Address: JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
Company website: kodakpixpro.com
INDUSTRY CANADA
This device complies with Canadian RSS210.
This device complies with Industry Canada license-exempt RSS standard (s).Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Radiation Exposure Statement:
This product complies with the Canadian portable RF exposure limit set forth for an uncontrolled
environment and is safe for intended operation as described in this manual. Additional RF exposure
reduction can be achieved if the product can be kept as far as possible from the user body or set the device
to lower output power if such function is available.
BEFORE YOU START

Kodak PIXPRO WPZ2 Specifications

General

Megapixel	16.76 MP
Camera type	Compact camera
Sensor type	BSI CMOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	EXIF, JPEG
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	(4:3) 16MP: 4608x3456, 10MP: 3648x2736, 5MP: 2592x1944, 3MP: 2048x1536, 0.3MP: 640x480, (3:2) 14MP: 4608x3072, (16:9) 12MP: 4608x2592, 2MP: 1920x1080
Digital zoom	6 x
Optical zoom	4 x
Combined zoom	24 x
Focal length range	4.9 - 19.6 mm
Lens structure (elements/groups)	7/7
Maximum focal length (35mm film equiv)	108 mm
Minimum focal length (35mm film equiv)	27 mm
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	4 s
Flash modes	Auto, Fill-in, Forced off, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 2.4 m
Flash range (wide)	0.3 - 5.2 m
Flash recharging time	6 s
Memory slots	1
Internal memory	8 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	32 GB
PictBridge	-
USB version	2.0
USB connector	Micro-USB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Battery type	LB-015
Battery voltage	3.7 V
Battery capacity	700 mAh
Product color	Blue
Waterproof up to	15 m
White balance	Auto, Cloudy, Daylight, Fluorescent, Incandescent, Manual, Underwater
Shooting modes	Auto, Movie
Self-timer delay	- s
Display diagonal	2.7 \
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200
ISO sensitivity (max)	3200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Multi Point Auto Focus, Single Auto Focus
Normal focusing range (tele)	1 — ∞ m
Normal focusing range (wide)	0.6 — ∞ m
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels

Weight and Dimensions

Depth	52.4 mm
Width	103.2 mm
Height	66.7 mm
Weight	176 g
