Kodak PIXPRO WPZ2 User Manual

92
PICTBRIDGE™ technology allows printing of the
photos saved on the memory card by a printer.
To ind out if a printer is PICTBRIDGE™ compatible,
simply look for the PICTBRIDGE™ logo on the
packaging or check the owner's manual for
speciications. With the PICTBRIDGE™ function on
your camera, you can print the captured photos
directly to a PICTBRIDGE™ compatible printer
using the supplied USB cable, without the need for
a PC.
Setting the USB Mode
The camera’s USB port can be set to connect with
either a PC or a printer. The following steps will
ensure that the camera is correctly conigured to
connect with a compatible printer.
1. Press the button, press the up/down arrow
buttons to select and press the button to
enter the menu.
2. Press the up/down arrow buttons to select
and press the button or right arrow button to
enter the menu.
Connecting to PICTBRIDGE™ Compatible Printers
3. Press the up/down arrow buttons to select
[USB] and press the button or right arrow
button to enter the menu.
4. Press the up/down arrow buttons to select
[Printer] and press the button to conirm.
USB
PC
Printer
After the camera is reset, it will switch to PC
mode automatically from USB Mode.
See “Using the PICTBRIDGE™ Menu“ section
on page 94.

Kodak PIXPRO WPZ2 Specifications

General

Megapixel	16.76 MP
Camera type	Compact camera
Sensor type	BSI CMOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	EXIF, JPEG
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	(4:3) 16MP: 4608x3456, 10MP: 3648x2736, 5MP: 2592x1944, 3MP: 2048x1536, 0.3MP: 640x480, (3:2) 14MP: 4608x3072, (16:9) 12MP: 4608x2592, 2MP: 1920x1080
Digital zoom	6 x
Optical zoom	4 x
Combined zoom	24 x
Focal length range	4.9 - 19.6 mm
Lens structure (elements/groups)	7/7
Maximum focal length (35mm film equiv)	108 mm
Minimum focal length (35mm film equiv)	27 mm
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	4 s
Flash modes	Auto, Fill-in, Forced off, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 2.4 m
Flash range (wide)	0.3 - 5.2 m
Flash recharging time	6 s
Memory slots	1
Internal memory	8 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	32 GB
PictBridge	-
USB version	2.0
USB connector	Micro-USB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Battery type	LB-015
Battery voltage	3.7 V
Battery capacity	700 mAh
Product color	Blue
Waterproof up to	15 m
White balance	Auto, Cloudy, Daylight, Fluorescent, Incandescent, Manual, Underwater
Shooting modes	Auto, Movie
Self-timer delay	- s
Display diagonal	2.7 \
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200
ISO sensitivity (max)	3200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Multi Point Auto Focus, Single Auto Focus
Normal focusing range (tele)	1 — ∞ m
Normal focusing range (wide)	0.6 — ∞ m
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels

Weight and Dimensions

Depth	52.4 mm
Width	103.2 mm
Height	66.7 mm
Weight	176 g
