Kodak PIXPRO WPZ2 User Manual

39
1. Rotate the mode dial to and then enter the
Wi-Fi selection interface.
2. Press the left/right arrow buttons to select and
set options.
Settings Station AP mode
Wi-Fi Mode
In AP mode, the camera will act
as an access point enabling another
Wi-Fi device to connect to it.
 [Settings] ：
Customize the Wi-Fi settings for the camera
system.
 [Station] ：
Use the Station Mode to connect to a
“Personal Hotspot” created by your mobile
device.
 [AP Mode] ：
In AP mode, the camera will act as an
access point enabling another Wi-Fi device
to connect to it.
Press the mode button to disconnect.
AP Mode
This camera may connect with your smart device
through Wi-Fi.
Settings of Camera:
1. Select and press the button to enter the
setting interface.
2. Press the up/down buttons to select options to
be adjusted, and press the button to enter
the option setting interface.
AP mode
Back
Refresh
Setting pre-connected device for the
following serial number:
SSID:
PIXPRO WPZ2_XXXX
WPA2-PSK: XXXXXXXX



Kodak PIXPRO WPZ2 Specifications

General

Megapixel	16.76 MP
Camera type	Compact camera
Sensor type	BSI CMOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	EXIF, JPEG
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	(4:3) 16MP: 4608x3456, 10MP: 3648x2736, 5MP: 2592x1944, 3MP: 2048x1536, 0.3MP: 640x480, (3:2) 14MP: 4608x3072, (16:9) 12MP: 4608x2592, 2MP: 1920x1080
Digital zoom	6 x
Optical zoom	4 x
Combined zoom	24 x
Focal length range	4.9 - 19.6 mm
Lens structure (elements/groups)	7/7
Maximum focal length (35mm film equiv)	108 mm
Minimum focal length (35mm film equiv)	27 mm
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	4 s
Flash modes	Auto, Fill-in, Forced off, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 2.4 m
Flash range (wide)	0.3 - 5.2 m
Flash recharging time	6 s
Memory slots	1
Internal memory	8 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	32 GB
PictBridge	-
USB version	2.0
USB connector	Micro-USB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Battery type	LB-015
Battery voltage	3.7 V
Battery capacity	700 mAh
Product color	Blue
Waterproof up to	15 m
White balance	Auto, Cloudy, Daylight, Fluorescent, Incandescent, Manual, Underwater
Shooting modes	Auto, Movie
Self-timer delay	- s
Display diagonal	2.7 \
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200
ISO sensitivity (max)	3200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Multi Point Auto Focus, Single Auto Focus
Normal focusing range (tele)	1 — ∞ m
Normal focusing range (wide)	0.6 — ∞ m
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels

Weight and Dimensions

Depth	52.4 mm
Width	103.2 mm
Height	66.7 mm
Weight	176 g
