Kodak PIXPRO WPZ2 User Manual

6
If there is dust, sand or other foreign materials on
the waterproof rubber of the battery cover and its
contact surface, please wipe it with a clean, dry
and lint free cloth as soon as possible.
Before using the product underwater, make sure
that there is no damage to or foreign debris on
the waterproof rubber gasket. Then close the
battery cover tightly to ensure the waterproof
capability of the product.
Waterproof rubber with scratches and cracks
will allow water to penetrate into the product.
Contact customer service immediately
for maintenance with replacement of new
waterproof rubber.
SAFETY NOTES
Waterproof / Dustproof / Shockproof
JIS / IEC waterproof grade 8 (IPX8).
JIS / IEC dustproof grade 6 (IP6X).
Height for shockproof rating is 2m (6.6 feet).
Waterprooing Notes:
Do not use the product below 15 meters (49.2
feet) underwater. The product can remain
waterproof for one hour at the depth of 15m
(49.2 feet).
Do not use this product in a geothermal spring
or in water at a temperature greater than 40 °C
(104°F).
Please do not open the battery cover
underwater.
If water accidentally comes in contact with the
product, please do not open the battery cover.
Turn the product o, and dry it with a clean, dry
and lint free cloth. Then open the battery cover,
and remove the battery and the memory card.
When opening the battery cover, if there are
water drops on the contact surface between
the inside of the battery cover and the body,
please dry the water drops.
After using the product in water or near sand,
mud or other foreign materials, please rinse it
with clean water (close the battery cover before
cleaning). After cleaning, dry the product with a
clean, dry and lint free cloth.
Waterproof Rubber

Kodak PIXPRO WPZ2 Specifications

General

Megapixel	16.76 MP
Camera type	Compact camera
Sensor type	BSI CMOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	EXIF, JPEG
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	(4:3) 16MP: 4608x3456, 10MP: 3648x2736, 5MP: 2592x1944, 3MP: 2048x1536, 0.3MP: 640x480, (3:2) 14MP: 4608x3072, (16:9) 12MP: 4608x2592, 2MP: 1920x1080
Digital zoom	6 x
Optical zoom	4 x
Combined zoom	24 x
Focal length range	4.9 - 19.6 mm
Lens structure (elements/groups)	7/7
Maximum focal length (35mm film equiv)	108 mm
Minimum focal length (35mm film equiv)	27 mm
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	4 s
Flash modes	Auto, Fill-in, Forced off, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 2.4 m
Flash range (wide)	0.3 - 5.2 m
Flash recharging time	6 s
Memory slots	1
Internal memory	8 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	32 GB
PictBridge	-
USB version	2.0
USB connector	Micro-USB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Battery type	LB-015
Battery voltage	3.7 V
Battery capacity	700 mAh
Product color	Blue
Waterproof up to	15 m
White balance	Auto, Cloudy, Daylight, Fluorescent, Incandescent, Manual, Underwater
Shooting modes	Auto, Movie
Self-timer delay	- s
Display diagonal	2.7 \
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200
ISO sensitivity (max)	3200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Multi Point Auto Focus, Single Auto Focus
Normal focusing range (tele)	1 — ∞ m
Normal focusing range (wide)	0.6 — ∞ m
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels

Weight and Dimensions

Depth	52.4 mm
Width	103.2 mm
Height	66.7 mm
Weight	176 g
