Kodak PIXPRO WPZ2 User Manual

20
Before you charge your battery, make sure the
camera is o and the battery is inserted correctly.
1. Connect the camera to the power charger using
the supplied USB cable.
2. Insert the plug of the power charger into the
wall outlet to charge the battery.
The charger is for indoor use only.
After the battery is stored for long periods of
time, use the supplied power charger to fully
charge the battery prior to use.
Charging Indicator:
Steady orange : Charging
The indicator lamp will go out once charging
is inished and the camera will power o
automatically. To maximize battery life,
charge the battery for at least 4 hours the
irst time.
When the camera is turned o, you can also
connect the camera to your PC using a USB
cable to charge the battery.
Please charge the battery indoors between
0°C and 40°C (32°F and 104°F).
Charging the Battery
1
2
3

Kodak PIXPRO WPZ2 Specifications

General

Megapixel	16.76 MP
Camera type	Compact camera
Sensor type	BSI CMOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	EXIF, JPEG
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	(4:3) 16MP: 4608x3456, 10MP: 3648x2736, 5MP: 2592x1944, 3MP: 2048x1536, 0.3MP: 640x480, (3:2) 14MP: 4608x3072, (16:9) 12MP: 4608x2592, 2MP: 1920x1080
Digital zoom	6 x
Optical zoom	4 x
Combined zoom	24 x
Focal length range	4.9 - 19.6 mm
Lens structure (elements/groups)	7/7
Maximum focal length (35mm film equiv)	108 mm
Minimum focal length (35mm film equiv)	27 mm
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	4 s
Flash modes	Auto, Fill-in, Forced off, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 2.4 m
Flash range (wide)	0.3 - 5.2 m
Flash recharging time	6 s
Memory slots	1
Internal memory	8 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	32 GB
PictBridge	-
USB version	2.0
USB connector	Micro-USB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Battery type	LB-015
Battery voltage	3.7 V
Battery capacity	700 mAh
Product color	Blue
Waterproof up to	15 m
White balance	Auto, Cloudy, Daylight, Fluorescent, Incandescent, Manual, Underwater
Shooting modes	Auto, Movie
Self-timer delay	- s
Display diagonal	2.7 \
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200
ISO sensitivity (max)	3200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Multi Point Auto Focus, Single Auto Focus
Normal focusing range (tele)	1 — ∞ m
Normal focusing range (wide)	0.6 — ∞ m
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels

Weight and Dimensions

Depth	52.4 mm
Width	103.2 mm
Height	66.7 mm
Weight	176 g
