Kodak PIXPRO WPZ2 User Manual

4
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference
by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modiications not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Radiation Exposure Statement:
This product complies with the FCC portable RF exposure limit set forth for an uncontrolled environment
and is safe for intended operation as described in this manual. Additional RF exposure reduction can be
achieved if the product can be kept as far as possible from the user body or set the device to lower output
power if such function is available.

Kodak PIXPRO WPZ2 Specifications

General

Megapixel	16.76 MP
Camera type	Compact camera
Sensor type	BSI CMOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	EXIF, JPEG
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	(4:3) 16MP: 4608x3456, 10MP: 3648x2736, 5MP: 2592x1944, 3MP: 2048x1536, 0.3MP: 640x480, (3:2) 14MP: 4608x3072, (16:9) 12MP: 4608x2592, 2MP: 1920x1080
Digital zoom	6 x
Optical zoom	4 x
Combined zoom	24 x
Focal length range	4.9 - 19.6 mm
Lens structure (elements/groups)	7/7
Maximum focal length (35mm film equiv)	108 mm
Minimum focal length (35mm film equiv)	27 mm
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	4 s
Flash modes	Auto, Fill-in, Forced off, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 2.4 m
Flash range (wide)	0.3 - 5.2 m
Flash recharging time	6 s
Memory slots	1
Internal memory	8 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	32 GB
PictBridge	-
USB version	2.0
USB connector	Micro-USB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Battery type	LB-015
Battery voltage	3.7 V
Battery capacity	700 mAh
Product color	Blue
Waterproof up to	15 m
White balance	Auto, Cloudy, Daylight, Fluorescent, Incandescent, Manual, Underwater
Shooting modes	Auto, Movie
Self-timer delay	- s
Display diagonal	2.7 \
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200
ISO sensitivity (max)	3200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Multi Point Auto Focus, Single Auto Focus
Normal focusing range (tele)	1 — ∞ m
Normal focusing range (wide)	0.6 — ∞ m
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels

Weight and Dimensions

Depth	52.4 mm
Width	103.2 mm
Height	66.7 mm
Weight	176 g
