Transportation - Storage
Dimensions and weight
Fig. 38: Dimensions and weight of engine
Information
u RFOB stands for “Rear Face of Block”.
Designation Ref.
Dimensions
Standard engine EATS configuration
Overall length 2633 mm
8.64 ft
2633 mm
8.64 ft
Overall width 1647 mm
5.4 ft
1650 mm
5.41 ft
Overall height 2167 mm
7.11 ft
2168 mm
7.11 ft
From RFOB to center of gravity X1 857 mm
2.81 ft
913 mm
3 ft
From RFOB to lifting point - right side X2 334 mm
1.1 ft
334 mm
1.1 ft
56
© 2022 by Kohler Co. All rights reserved.
KD62V12 33521030301_8_1 EN_US 2022-09
