Transportation - Storage
Dimensions and weight
Designation Ref.
Dimensions
Standard engine EATS configuration
From RFOB to lifting point - left side X3 285 mm
11.22 in
285 mm
11.22 in
Distance between engine lifting points
- right side
X4 1040 mm
3.41 ft
1040 mm
3.41 ft
Distance between engine lifting points
- left side
X5 780 mm
2.56 ft
780 mm
2.56 ft
Axis to center of gravity Y1 305 mm
1 ft
312.4 mm
1.02 ft
Axis to lifting point Y2 729 mm
2.39 ft
729 mm
2.39 ft
From center of gravity to lifting point Z1 645 mm
2.12 ft
645 mm
2.12 ft
Distance between engine lifting points Z2 1290 mm
4.23 ft
1290 mm
4.23 ft
Axis to center of gravity Z3 11 mm
0.43 in
7.6 mm
0.3 in
Maximum weight P 9250 kg
20,392 lb
9350 kg
20,613 lb
Maximum angles of lifting devices —
side view
α1–α2
15° 15°
Maximum angles of lifting devices —
front view
β1–β2
15° 15°
Tab. 13: Dimensions and weight of engine - values
KD62V12 33521030301_8_1 EN_US 2022-09
© 2022 by Kohler Co. All rights reserved.
57
