GENERAL INFORMATION
1
9
EN
Some components are for illustrative purposes only and may vary.
NOTE: Components in Pos. 8, 10 are not supplied by Kohler.
POS.
DESCRIPTION
1
ECU
2
EGR Cooler
3
High-pressure fuel injection pump
4
Oil cooler
5
Fuel filter
6
Oil filler side cap
7
Oil dipstick
8
AC compressor
9
Lub. oil filter
10
Brake compressor
11
Thermostatic valve
12
EGR valve
13
Turbocharger
14
Air inlet valve
15
Oil steam separator
16
Alternator
17
Coolant pump
18
Starter motor
19
Oil sump
20
Flywheel
21
Oil drain plug
22
Wiring
23
Oil filler cap

Kohler KDI 3404TCR-SCR Specifications

General

Brand	Kohler
Model	KDI 3404TCR-SCR
Category	Engine
Language	English
