Operation 2-5TP-5672 11/95
Microprocessor-Controlled Transfer Logic
Standard Switch
Normal Source Failure
Time Delay Engine Start
Time Delay Normal-to-Emergency
Load Shed (all)—if equipped
Inphase Monitor—if equipped
Contactor Transfer to Emergency Position
Normal Source Return
Load Return (programmed sequence)—if equipped
Time Delay Emergency-to-Normal
Load Shed (all)—if equipped
Inphase Monitor—if equipped
Contactor Transfer to Normal Position
Load Return (programmed sequence)—if equipped
Time Delay Engine Cooldown
