C-1
TP-5672 11/95
APPENDIX C
Commonly Used Accessories
Standard Accessories
D Controller contains a CMOS microprocessor and nonvolatile
memory.
D Microprocessor provides digital accuracy for time-delay,
source-transfer, and generator set exerciser intervals.
D Controller is protected against EMI,voltage transients, ESD,
shock, vibration, and other hostile environments per U.S.A.,
Canadian, and IEC standards.
D All printed circuit boards are conformal coated for
environmental protection.
D Transfer switches with microprocessor logic have area
protection with override.
D The normal source voltage is monitored across live lines of
single-phase switches, and all phases of normal source are
monitored line-to-line on three-phase switches.
D Theemergency source voltageandfrequency aremonitored
across one phase.
D User-adjustable time delays include: Normal to Emergency
(TDNE), Engine Start (TDES), Emergency to Normal
(TDEN), Engine Cooldown (TDEC), Off to Emergency
(TDOE), and Off to Normal (TDON).
D Each microprocessor-controlledtransferswitchwith aNEMA
type 1 enclosure has a front-accessible status panel.
D An LCD display, touch key pad, and LED indicating lights
allow user interaction with the controller.
D Generator set exercising intervals can be selected from
seven-day, fourteen-day, or calendar settings.
D The test switch simulates a normal source power failure.
D Ambienttemperaturerange: Operating-20_ Fto+150_ F,
±2% accuracy
Storage-60_Fto+220_F
D Transfer Switch Humidity: 0 to 100% noncondensing,
operatingandstorage.
Shunt/Jumper-Controlled Accessories
- DD-100-B Extended Time Delay, adjustable from 0 to 99
minutes. Affects accessories TDNE, TDEN, TDES,
TDOE, TDON, TDEC, and Load sequence, if
ordered.
- DD-23-C No-load plant exerciser with override. Choice of
7-day, 14-day, or calendar-based exercise modes.
- DD-34-A Inphase monitor, both directions. Not available on
ATS withthe programmed transition function.
- DD-34-J Overvoltage sensing all phases,
over/underfrequency sensing for one phase on
normal source, and overvoltage/frequency sensing
one phase on emergency source
- DD-34-Z Phase rotation and anti-single-phasing protection.
Requires option DD-05-K for emergency source
sensing.
Optional Accessories
Source Monitors, Emergency
- DD-05-K Overfrequency sensing, 1-phase,
over/undervoltage sensing 3-phase, phase rotation
and anti-single-phasing protection
Two-Position Test Switch
- DD-06-F Momentary AUTO/TEST simulates normal power
failure, key-operated
Three-Position Test Switches
- DD-06-N Momentary TEST/AUTO/ENGINE START
- DD-06-P Momentary TEST/AUTO/ENGINE START,
key-operated
Four-Position Test Switch
- DD-07-D TEST/AUTO/OFF/ENGINE START
Time Delay Override Switch
- DD-08-C Time delay emergency-to-normal
- DD-08-D Time delay normal-to-emergency
Preferred source switch
- DD-10-D Two position switch for use with two generator
sets.
Auxiliary Contacts
- DD-14-G Ten-contact kit for remote indication. Contacts
rated 10 amps., 125 vac. Indicates contactor
positions, sources available, program mode, and
system alarm.
- DD-14-H Single-contact kit for remote indication, rated 10
amps., 120 vac, in normal contact position
- DD-14-J Indicates contactor in emergency position
- DD-14-K Indicates normal source present
- DD-14-L Indicates emergency source present
- DD-14-M Indicates ATS not in AUTO
- DD-14-N Indicates program switch not in OFF
- DD-14-P Indicates system alarm
- DD-14-R Load bank control
- DD-14-S Indicates contactor in off position
NOTE: A maximum of two DD-14-H through DD-14-S may be
fitted to a transfer switch, either by themselves or in
addition to one DD-14-G
Auxiliary Contacts—Main Shaft Position. Dependent on
power switch.
- DD-15-E One additional closed on normal
- DD-15-F One additional closed on emergency
Meters
- DD-18-G Frequency meter, analog, fused
- DD-18-J Voltmeter and ammeter, analog, fused
Plant Exercisers
- DD-23-D Plant exerciser, load transfer with override. Choice
of 7-day, 14-day, or calendar-based modes.
- DD-23-G Plant exerciser, load/no-load transfer with
two-position selector switch and override. Choice
of 7-day, 14-day, or calendar-based modes.
