5-29
Accessory Troubleshooting
TP-5672 11/95
Use the following table to find the troubleshooting
flowchart for Option DD-18-J Current and Voltage
meters. Locate the DD-18-J accessory that is used on
your transfer switch in the left column. The flowchart
numberfor troubleshooting the voltmeter is in thecenter
column and the flowchart for troubleshooting the
ammeter is in the right column.
Options
with
DD-18-
Prefix
Voltmeter Troubleshooting
Ammeter
Troubleshooting
Flowchart
JA1 Figure 5-36 Figure 5-37
JA2 Figure 5-40 to Figure 5-45 Figure 5-46
JA3 Figure 5-36 Figure 5-37
JA4 Figure 5-38 Figure 5-39
JA5 Figure 5-40 to Figure 5-45 Figure 5-46
JA8 Figure 5-47 to Figure 5-52 Figure 5-46
JA9 Figure 5-47 to Figure 5-52 Figure 5-46
JA10 Figure 5-47 to Figure 5-52 Figure 5-46
JB1 Figure 5-36 Figure 5-37
JB2 Figure 5-40 to Figure 5-45 Figure 5-46
JB3 Figure 5-36 Figure 5-37
JB4 Figure 5-38 Figure 5-39
JB5 Figure 5-40 to Figure 5-45 Figure 5-46
JB6 Figure 5-47 to Figure 5-52 Figure 5-46
JB8 Figure 5-47 to Figure 5-52 Figure 5-46
JB9 Figure 5-47 to Figure 5-52 Figure 5-46
JB10 Figure 5-47 to Figure 5-52 Figure 5-46
JC1 Figure 5-36 Figure 5-37
JC2 Figure 5-40 to Figure 5-45 Figure 5-46
JC3 Figure 5-36 Figure 5-37
JC4 Figure 5-38 Figure 5-39
JC5 Figure 5-40 to Figure 5-45 Figure 5-46
JC8 Figure 5-47 to Figure 5-52 Figure 5-46
JC9 Figure 5-47 to Figure 5-52 Figure 5-46
JC10 Figure 5-47 to Figure 5-52 Figure 5-46
JD1 Figure 5-36 Figure 5-37
JD2 Figure 5-40 to Figure 5-45 Figure 5-46
JD3 Figure 5-36 Figure 5-37
JD4 Figure 5-38 Figure 5-39
Options
with
DD-18-
Prefix
Voltmeter Troubleshooting
Ammeter
Troubleshooting
Flowchart
JD5 Figure 5-40 to Figure 5-45 Figure 5-46
JD8 Figure 5-47 to Figure 5-52 Figure 5-46
JD9 Figure 5-47 to Figure 5-52 Figure 5-46
JD10 Figure 5-47 to Figure 5-52 Figure 5-46
JE1 Figure 5-36 Figure 5-37
JE2 Figure 5-40 to Figure 5-45 Figure 5-46
JE3 Figure 5-36 Figure 5-37
JE4 Figure 5-38 Figure 5-39
JE5 Figure 5-40 to Figure 5-45 Figure 5-46
JE8 Figure 5-47 to Figure 5-52 Figure 5-46
JE9 Figure 5-47 to Figure 5-52 Figure 5-46
JE10 Figure 5-47 to Figure 5-52 Figure 5-46
JF1 Figure 5-36 Figure 5-37
JF2 Figure 5-40 to Figure 5-45 Figure 5-46
JF3 Figure 5-36 Figure 5-37
JF4 Figure 5-38 Figure 5-39
JF5 Figure 5-40 to Figure 5-45 Figure 5-46
JF6 Figure 5-47 to Figure 5-52 Figure 5-46
JF8 Figure 5-47 to Figure 5-52 Figure 5-46
JF9 Figure 5-47 to Figure 5-52 Figure 5-46
JF10 Figure 5-47 to Figure 5-52 Figure 5-46
JG1 Figure 5-36 Figure 5-37
JG2 Figure 5-40 to Figure 5-45 Figure 5-46
JG3 Figure 5-36 Figure 5-37
JG4 Figure 5-38 Figure 5-39
JG5 Figure 5-40 to Figure 5-45 Figure 5-46
JG8 Figure 5-47 to Figure 5-52 Figure 5-46
JG9 Figure 5-47 to Figure 5-52 Figure 5-46
JG10 Figure 5-47 to Figure 5-52 Figure 5-46
JH1 Figure 5-36 Figure 5-37
JH2 Figure 5-40 to Figure 5-45 Figure 5-46
JH3 Figure 5-36 Figure 5-37
JH4 Figure 5-38 Figure 5-39
JH5 Figure 5-40 to Figure 5-45 Figure 5-46
JH6 Figure 5-47 to Figure 5-52 Figure 5-46
JH8 Figure 5-47 to Figure 5-52 Figure 5-46
JH9 Figure 5-47 to Figure 5-52 Figure 5-46
JH10 Figure 5-47 to Figure 5-52 Figure 5-46
Figure 5-34. Option DD-18, analog meters troubleshooting table
Option 18-JXXX, analog meters
Turn ratio of transformer
JA1-5, JA8-10 30-5
JB1-6, JB8-10 75-5
JC1-5, JC8-10 100-5
JD1-5, JD8-10 150-5
JE1-5, JE8-10 300-5
JF1-6, JF8-10 400-5
JG1-5, JG8-10 600-5
JH1-5, JH8-10 800-5
Figure 5-35. Transformer Turn Ratio
