11
Note: Check that the air conditioner cabinet is tilted back about 1 1/8” to 1 1/2”, which should be
about 3-4 degrees downward to the outside. After proper installation, condensation should not
drain from the overow drain hole during normal use. If it does, correct the slope.
2. Extend both side curtains outward until they are ush with the window frame.
3. Attach Curtain Brackets
• The curtain brackets will secure the lower frame of the side curtains to the window sill.
• Place the curtain bracket in between the accordion extensions as shown in the image below.
• Use one (1) ½” Phillips head screw to attach the curtain brackets to the window sill.
• Repeat this procedure for the remaining side curtain.
Note: Use a 1/8” drill bit to drill pilot holes in the window sill to prevent splitting before driving
the screws into place.
