13
2. Install Energy Ecient Insulation Panels (WAC15003WCO only)
• This unit comes with insulating sheets. Install them into each side curtain to maximize energy eciency.
• Start by measuring the inner width of both side curtains.
• Locate the insulation panel supplied with this unit and cut each panel to the correct width.
• Slide the insulation panels into each side curtain as shown below with the pattern side facing inward (indoors).
3. Attach Weather Stripping
• In order to minimize air leaks, this unit comes with weather stripping that should be installed as needed to plug
any gaps that may be present after you have secured the air conditioner into the window.
• Inspect all potential air gaps around the window opening.
• Cut to size and attach weather stripping as needed.
Completing Installation
Now that you have completed the installation steps, your air conditioner is ready for use.
1. Plug the power cord into a properly grounded 3-prong outlet.
2. Press RESET on the LCDI plug.
3. Read the Control Panel Operations section for instructions on all modes and settings for the unit.
