Fresh Air Vent:
The Fresh Air Vent allows the air conditioner to:
1. Recirculate room air (Fig. A)
2. Draw fresh air in from the outside (Fig. B)
3. Recirculate room air and draw in fresh air from the outside (Fig. C)
WAC8003WCO, WAC10003WCO, and WAC12003WCO:
WAC 15003WCO:
FIG A: Closed
FIG A: Closed
FIG B: Vent Open
for Fresh Air
FIG B: Vent Open
for Fresh Air
FIG C: Vent and
Exhaust Open
FIG C: Vent and
Exhaust Open
Air Louvers:
The 4-way air directional louvers allow you to direct the air ow Up, Down, Left, and Right throughout the room
as needed. Use the center handles to adjust the air directional louvers side to side.
