23
FLASH BRIGHTNESS
Mode for adjusting the flash brightness on the screen.
Press the 1P start button to select an item. Pull the 1P or 2P gun trigger to modify
the setting.
To return to the main menu screen, select “SAVE AND EXIT” or “EXIT” and pull the
trigger of the 1P gun.
Adjusting the brightness of flashes.
•It is advisable to adjust the brightness depending on the brightness of the
installation place.
FLASH BRIGHTNESS
1PLYR START = SELECT OPTION
1PLYR AND 2PLYR TRIGGER = MODIFY SETTING
0.00 1.00
R = 0.75
G = 0.75
B = 1.00
FLASH TEST
FACTORY SETTING
SAVE AND EXIT
EXIT
(NEED TO PULL 1PLYR TRIGGER)
•Adjusts the red color brightness.
•Adjusts the green color brightness.
•Adjusts the blue color brightness.
•Displays the color brightness adjusted.
Pull the 1P gun trigger to do the flash test.
•Pull the 1P gun trigger to see if all the settings in this
mode go back to the factory ones.
5 PCB settings
•This screen is just an example.
