6 Installation and assembling
3
Attach sensor frame (as shown in
the picture to the right), to the top
of the vertical support bars. Fasten
the bolts provided on each side
of
the sensor frame where it meets
the vertical support bars
simultaneously.
4
Fasten the bolts provided on each
side of the sensor frame where it
meets the vertical support bars
simultaneously, as shown in the
right. The back end of the sensor
frame will lay on the roof of the
cabinet.
5
I
Fasten six hat brackets which fit
over the sensor frame on the roof
of the cabinet. As shown in the next
two pictures to the right.
(Make
sure to fasten six hat brackets]
to fit over the sensor frame on the
jrooioithacslinplMEMO
J
Front
30
To Next Page
