Changingbetweenresponderand
transpondermode
Thetranspondercanalsobeusedasaresponderunit.
Prerequisites
Thetranspondermustbechargedbeforeuse.
BydefaultwhenthecNODEMiniSisturnedonitisintranspondermode.
Thesignalinputfortheresponderfunctionmustbebetween2and6mswithapositive
pulseof5to24V .
Procedure
1Whenrespondertriggersignalsarereceived,themodeisautomaticallychanged
toresponder.
2Oncetherespondertriggersignalsstop,itwilltake1minutebeforethecNODE
MiniSchangesautomaticallybacktotranspondermode.
TurningontheTTC
UsetheTransponderTestandCongurationunittocheckthatthetransponderisready
foruse.
Procedure
1Openthesuitcase.
2Turnonthemainpowerswitchtostartthe
program.
Thistakesapproximately1.5minutes.
Acoustictest
Testthetransponderacousticstomakesureitisfunctioning..
Procedure
1SetTTCPowerbyusingtheleft/rightarrowstoselectthepowerlevelandtap
Settoconrmyourselection.
2Connectthetesttransducercabletotheupperrightconnector.
cNODEMiniSInstructionManual
