Kongsberg cNODE MiniS User Manual

397152/E
9
Systemdescription
cNODEMiniSisafamilyoftranspondersforunderwaterpositioninganddatalinks,and
operateswithHiPAPandcPAPtransceivers.
ThecNODEMiniStranspondersareidealfor
positioningROVs.Theyhaveresponderand
transponderfunctionality,SSBLandLBLpositioning,
andtelemetrycapabilities.
cNODEMiniSiscompatiblewithbothCymbal
protocolforpositioninganddatalinkandFSKchannelsandtelemetry.
Thetranspondersareratedupto7000metresdependingonthehousing.Theyhavean
internaltiltsensor±90°,anexternalon/offfunctionandapressurereliefvalveforsafety
purposes.Severalmodelsareavailablewithdedicatedpressuresensors.
cNODEMiniSispoweredfromaninternalrechargeableLi–Ionbattery,andcanbe
poweredfromROVs24Vduringoperation.Anon-deckbatterychargerisavailable.
Updatethecongurationandthesoftwareviaanexternalconnector.TTC30canbe
usedfortestandconguration.
Namingdescription
Thetranspondernameconsistsofthemodelname,themodelnumber,thetransducer
beamwidthandanyoptionsincluded.
Modelname
cNODEMiniS
Modelnumber
Firstdigit=Frequencyband
•3=30kHz
Seconddigit=Depthrating
•1=1000m
•4=4000m
•7=7000m
Optionaltranspondermodules
PS:Pressuresensor
S:Splitversionforremotetransducers
cNODEMiniS
