Orderingspareparts

Tomaketheorderprocessasshortandefcientaspossible,youmustprovideaccurate

informationabouttheproduct,thepartyouneed,andyourself.

Thefollowinginformationmustbeprovidedwithyourorder:

•Partnameand/ordescription

•Ourpartnumber

•Numberofitemsrequired

•Yourshipmentaddress

•Preferredshipmentmethod

•Requireddateofdeliveryfromus

Forcertainspareparts(typicallycompleteunits,printedcircuitboardsandsoftware)the

vesselnameisalsouseful,asthisallowsustoupdateourvesseldatabase.

cNODEMiniS34-180sparepart

•Partname:MiniS34-180

•Partnumber:396588

cNODEMiniS34-180PSsparepart

•Partname:MiniS34-180PS

•Partnumber:443399

cNODEMiniS31-180PSsparepart

•Partname:MiniS31-180PS

•Partnumber:443380
