40
397152/E
Congurationorpowerconnectorpinout
Theexternalconnectorisforconguration,responderfunction,on/offfunctionand
charging.
Thisisthepincongurationforamaleconnector,asseentowardstheconnector(face
view).
Pin1,2and3isforconguration.
Pin4and5isforresponderfunction.
Pin6and8isforon/offfunction.
Pin7and8isforexternalpower.
PinnumberSignal
1
2
3
4
Respondertrigger+
5
Respondertrigger-
6
On/Off
7
Externalpower(24VDC)
8
Ground
cNODEMiniSInstructionManual
