Kongsberg cNODE MiniS User Manual

397152/E
27
7Cleanthethreadsinthetransponderhousing.
8Feedthewiresonthenewconnectorthroughtheconnectorhole.
9UseLoctite243onthethreadsandapplyactivator.
10Inserttheconnector.
11Tightentheconnectorto10Nm.
12Installthecrimpterminalsinthereceptacleaccordingtothecabledrawing.
13PutthebatteryandthePCBbackinthetube.
14CheckandreplaceanydamagedO-ringsonthetransducerbeforereplacingit.
15ConnectthenewconnectorandthetransducertothePCB.
16Installthetransducer.
LubricatingSEACONconnectors
SEACONconnectorsrequireverylittlemaintenance.Theyaredesignedtobeused
inharshenvironmentsandthuslimitedamountsofdirtandgritdonotaffecttheir
performance.
Context
Itisrecommendedthat,upondisconnectingorretrievingthesystem,theconnectorsbe
cleaned,tostorage(ifpossible,rematewithdummyplugs).Priortodeploymentthe
followingmaintenanceprocedureisrecommended:
Procedure
1Dematetheconnectorset.
Maintenance
