Kongsberg cNODE MiniS User Manual

26
397152/E
Replacingtheconnector
Theconnectorkitconsistsofaconnector,areceptacle,crimpterminalsandacable
sleeve.
Context
Cablespecications
ThisistheMolexplugseenfromthebackwherethecrimpterminalsareinstalledanda
faceviewoftheconnector.
Procedure
1Removethetransducer.
2Disconnectthetransducercable(s).
3DisconnecttheconnectorplugfromthePCB.
4RemovethebatteryandthePCB.
5CuttheMolexplug.
6Useawrenchtoremovetheconnector.
Useawrenchwithaslim20mmsocket.Theouterdiameterofthesocketshouldbe
24mmorlesstoavoiddamagingthetransponderhousing.
