12
Utility mode
12-62 bizhub 751/601 (Version 2)
12.6.10 2-Position Staple Pitch Adjustment
The distance between staples when printing with the "2 Position" Staple setting ("Staple" and "Center Staple
& Fold") can be adjusted.
2
Note
[2-Position Staple Pitch Adjustment] does not appear if optional Finisher FS-610 is not installed.
0 Before making any adjustments, use the "2 Position" Staple setting to print a sample copy. Perform the
adjustment while checking the sample that was created.
1 Display the Administrator Settings screen.
– For details on displaying the Administrator Settings screen, refer to "Displaying the Administrator
Settings screen" on page 12-42.
2 Touch [1 System Settings].
The System Settings screen appears.
3 Touch [7 Expert Adjustment].
The Expert Adjustment screen appears.
4 Touch [5 Finisher Adjustment].
The Finisher Adjustment screen appears.
5 Touch [Forward ], and then touch [1 2-Position Staple Pitch Adjustment].
The Adjust Spacing of 2 Staples screen appears.
6 Touch the button for the setting to be adjusted.
7 Check the stapling positions in the sample copy.
– Touch [+] or [-] under "Adjust Value" to adjust the distance (between 128 mm and 160 mm) between
the staples.
– Each time [+] or [-] is touched, the value is increased or decreased by one increment.
8 Touch [OK].
The distance between the staples is adjusted.
If no adjustment of the distance between the staples was necessary in step 7, this completes the
procedure.
9 Use the "2 Position" Staple setting to print another sample copy.
To Next Page
