Introduction
x-34
C252
“Blue” parameter
This parameter c
an be used to
adjust the degree
of blue in
the image
to one
of 19 levels.
For details on the setting pro
cedure, refer to page
8-53.
Sample images
Original
+
3
–
3
34
36
Table of Contents
