4
Supplies & Handling
4-4 bizhub PRO C6501
To load paper in main body trays (tray 1 to 3)
0 If you want to use another paper than any loaded in the trays, temporarily
change the setting of the tray to be used. See page 9-44 for details.
1 Withdraw the tray to be supplied with paper.
– Withdraw the tray completely until the green line appears at the left
side of the tray. Otherwise, the paper feed roller may not open or
machine trouble may be caused.
2 Open the paper feed roller.
To load the same size as loaded before, proceed to step 4.
If changing the paper size, proceed to the next step.
3 Adjust the position of the side guide plate.
– Pull up the lock lever at the front, then slide the side guide plate to
the desired position.
– See the size indication on the bottom plate of the tray to determine
the position of the side guide plate.
– Push down the lock lever firmly until it clicks in position in order to
fix the side guide plate.
1
2
1
22
2
3
To Next Page
