4.10 Removing Finished Sets from Large Capacity Stacker
LS-505
The Large Capacity Stacker LS-505 can hold 5,000 output sheets (3,000
sheets for coated paper of Max. 13.0" × 19.0" (331 mm × 483 mm) to Min.
8.3" × 15.0" (210 mm × 380 mm) / 2,000 sheets for B5 and A5) at maximum.
Follow the procedure below to take out paper from the stacker.
2
Note
The paper stopper is provided to secure the paper in position when mov-
ing the carriage.
To remove finished sets
1 Press the Paper removal button.
The stacker unit will move down to
the carriage.
2 Open the large capacity stacker
door.
– Once the stacker holds a sheet of
output paper, the large capacity
stacker door will be locked and
cannot open till the stacker unit
goes down fully to the carriage.
