Korg Grandstage 88

17
Volume
(CC#7)
This is used to control the volume.
Controls the volume on the output line for both
the KEYBOARDS and ENSEMBLE sections. (*1)
Master
Volume
Controls the master volume.
This controls the volume at the last stage of
the sound generator output. At the same time,
this sends a master volume message (universal
exclusive message) to control the volume of all
outputs, including the REVERB/DELAY section
and the equalizer. (*3)
M. Wheel
(CC#1)
This allows the modulation wheel eect of the
Grandstage to be controlled by pedal.
MIDI
CC#0...
#95
Outputs the MIDI control change message that
is set. If the Grandstage supports this control
setting, the eect will be applied.
MIDI
CC#102...
#119
Outputs the MIDI control change message that
is set. If the Grandstage supports this control
setting, the eect will be applied.
*1:
Controls the volume of the REVERB/DELA
Y section and
the equalizer prior to input.
*2:
On the CX-3 type organ programs, this controls the volume
before the rotary speaker input. Recreates the ef
fect of an
expression pedal used with drawbar organs. The expression
pedal effect can be recreated in the same way for VOX organ
and electric organ programs as well.
*3:
The MASTER VOLUME knob adjusts the output level from
AUDIO OUTPUT
.
Foot - Switch (foot switch functions)
This sets the functions that will be controlled when a foot pedal
(such as the PS-1 or PS-3, sold separately) is connected to the
FOOT CONTROLLERS SWITCH jack on the rear panel. This
allows you to switch between favorites, as well as control sounds
and effects.
The default setting is “SW2 (CC#81)”.
Function Details
O The connected pedal will not function.
SW 1
(CC#80)
This controls the SW1 button eect using a foot
switch.
SW 2
(CC#81)
This controls the SW2 button eect using a foot
switch.
Soft
(CC#67)
Turns the soft pedal eect on or o.
Favorite
Up
Selects the next favorite number using a foot
switch. At the same time, this sends a program
change message.
Favorite
Down
Selects the previous favorite number using
a foot switch. At the same time, this sends a
program change message.
MIDI
CC#0...
#95
Outputs the MIDI control change message that
is set. If the Grandstage supports this control
setting, the eect will be applied.
MIDI
CC#102...
#119
Outputs the MIDI control change message that
is set. If the Grandstage supports this control
setting, the eect will be applied.
Calibrating the pedal
Damper Calib. (damper pedal calibration)
Calibrate the damper pedal (such as the DS-1H) that is connected
to the DAMPER jack. This will adjust the half-damper variable
range.
Tip:
The calibration set here will be stored in memory until you
perform the calibration again.
1. Connect the damper pedal to the Grandstage.
Refer to “FOOT CONTROLLERS” on page 10 for how to
connect the pedal.
2. Lift your foot o the damper pedal.
3. Press the SYSTEM button, and select “Damper
Calib.” using the VARIATION knob.
“[Press Pedal]” will blink on the third line of the display.
Note:
If you wish to cancel the calibration while
“[Press
Pedal]” is blinking, select a parameter using
the
VARIATION knob, or press the SYSTEM or
EXIT button to nish system settings.
4. Press the damper pedal down all the way until it
stops, and then lift your foot o the pedal.
Note:
The display will stop blinking and remain lit while
the damper pedal is being used. If nothing happens
even when you press the pedal, the pedal may not
be connected properly to the DAMPER jack. Check
the connections.
5. When the calibration is completed, the word
“Completed” will be shown on the third line of
the display.
Note:
If calibration was not correctly completed,
“[Press
Pedal]” will blink. Do step 4 once more.
6. To continue making other settings, use the
VARIATION knob to select the necessary
parameter.
Foot Sw Calib. (foot switch calibration)
Calibrate the switch-type foot pedal (such as the PS-1 or PS-3,
sold separately) that is connected to the SWITCH jack. This will
adjust the pedal’s variable range.
Tip:
The calibration set here will be stored in memory until you
perform the calibration again.
1. Connect the switch-type foot pedal to the
Grandstage.
Refer to “FOOT CONTROLLERS” on page 10 for how to
connect the pedal.
2. Lift your foot o the foot pedal.
3. Press the SYSTEM button, and select “Foot Sw
Calib.” using the VARIATION knob.
“[Press Pedal]” will blink on the third line of the display.
Note:
If you wish to cancel the calibration while
“[Press
Pedal]” is blinking, select a parameter using
the
VARIATION knob, or press the SYSTEM or
EXIT button to nish system settings.
4. Press the foot pedal down all the way until it
stops, and then lift your foot o the pedal.
Note:
The display will stop blinking and remain lit while
the foot pedal is being used. If nothing happens
even when you press the pedal, the pedal may not
be connected properly to the SWITCH jack. Check
the connections.
